The Oil/Water Separator has been designed by MK Environmental, Inc., specifically for groundwater remediation. The system available in 10, 20, 30, 50 and 75 gpm models, effectively removes 60 micron and larger oil droplets. The unit comes standard with gasketed aluminum lids to allow easy removal of the coalescing pack, if required. The coalescing pack is constructed of hydrocarbon resistant polypropylene with plates spaced 1-1/2” apart at a 60 degree angle for maximum separation and minimum maintenance.

Technical Specifications:

• 3/16” hot-rolled epoxy coated carbon steel construction
• Gasketed lid to allow easy removal & inspection of  the coalescing packing
• Coalescing packing constructed of hydrocarbon resistant polypropylene
• Coalescing packing spaced 1-1/2” apart at a 60 degree angle for maximum separation and minimum maintenance
• System(s) available in 10, 20, 30, 50 and 75 gpm models

  FUNCTIONAL DESCRIPTION

1. Separation of lighter than water hydrocarbons shall be done through the use of a combination of baffles and a clog-resistant interception incorporated within the separation system. The interceptor must be easily accessible to permit removal for cleaning
2. Integral to the Oil/Water Separator system shall be an intermittent product overflow basin with a minimum volume of 120 gallons.
3. Flow into the separator will be through a 3 inch NPT fitting. Flow through the separating unit will be by gravity. Effluent from the separator with be through a 3 inch NPT fitting.
4. Within each unit, baffles set perpendicular to the flow shall be supplied in order to dissipate inlet turbulence, to congeal solids for easier removal and to assist in oil/water separation.
5. The unit incorporates a hydrocarbon resistant polypropylene corrugated plate interceptor for the means of separation.
6. Hydrocarbons that have been separated will exit the separating stage via a 1-1/4” NPT fitting near the top of the separator and flow into the intermittent product overflow reservoir.
